01 — MIRA X-CESS Range

Manhole Covers & Frames

Square, rectangular, round and telecom access covers — hinged, bolted or locking — rated B125 through D400.

Square & Rectangular

B125

Product No.	Description	Type	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
1000	MIRA X-CESS 265×265	14A	✓	8	265×265	330×330	30
1001	MIRA X-CESS 265×265	14A	Cover only	5.6	265×265	300×300	30
1010	MIRA X-CESS 450×450	14B	✓	20	450×450	550×550	35
1100	MIRA X-CESS 450×600	25	✓	22	450×600	540×690	35
1050	MIRA X-CESS 600×600	9A	✓	35	600×600	700×700	40
1110	MIRA X-CESS 600×900	9E	Bolts	66	610×914	750×1054	60
1060	MIRA X-CESS 760×760	—	Bolts	65	758×758	894×894	60
1200	MIRA X-CESS 600×600 (Double seal)	8B	✓	65	610×610	825×825	60
1210	MIRA X-CESS 450×600 (Double seal)	8A	✓	37.5	450×600	590×740	50

Square & Rectangular

C250

Product No.	Description	Type	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
2100	MIRA X-CESS 200×200	—	✓	7	200×200	300×300	35
2150	MIRA X-CESS 300×300	—	✓	11	300×300	400×400	35
2200	MIRA X-CESS 400×400	—	✓	20	400×400	500×500	40
2500	MIRA X-CESS 450×600	9D	✓	39	450×600	570×720	50
2210	MIRA X-CESS 500×500	—	✓	29	500×500	600×600	45
2450	MIRA X-CESS 600×600	9B	✓	41	600×600	700×700	50
2420	MIRA X-CESS 600×600 (Concrete infill)	6	✓	65	600×600	700×700	90
2250	MIRA X-CESS 700×700	—	Bolts	55	700×700	800×800	60
2300	MIRA X-CESS 800×800	—	Bolts	77	800×800	900×900	65
2350	MIRA X-CESS 900×900	—	Bolts	104	900×900	1000×1000	70

Square & Rectangular

D400

Product No.	Description	Type	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
3100	MIRA X-CESS 450×600	117	✓	48	456×610	560×720	75
3150	MIRA X-CESS 600×600	—	✓	58	600×600	700×700	75
3200	MIRA X-CESS 900×900	—	Bolts	133	900×900	1000×1000	75
3210	MIRA X-CESS 1000×1000	—	Bolts	160	1000×1000	1100×1100	75
3215	MIRA X-CESS 1100×1100	—	Bolts	186	1100×1100	1200×1200	100

Telecom Rectangular Frame with Multi Triangular Covers

D400

Product No.	Description	Hinged	Lock	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
3900	MIRA X-CESS 600×600	✓	✓	85	600×600	750×750	100
3950	MIRA X-CESS 600×1200	✓	✓	163	600×1200	750×1470	100
3960	MIRA X-CESS 600×2260	✓	✓	340	600×2260	750×2420	100

Round

C250

Product No.	Description	Type	Hinged	Rubber ring	Lock	Mass (kg)	Internal	Height (mm)
2600	MIRA X-CESS 560	Y560	✓	✓	✓	36.5	560 round	2050

Round

D400

Product No.	Description	Type	Hinged	Rubber ring	Lock	Mass (kg)	Internal	Height (mm)
3500	MIRA X-CESS 600 Concrete infill	—	✓	✓	✓	58	600 dia	3400
3550	MIRA X-CESS 600	Z-600	✓	✓	✓	58	600 dia	3200

Square Frame, Round Cover

D400

Product No.	Description	Type	Hinged	Rubber ring	Lock	Mass (kg)	Internal	Height (mm)
3300	MIRA X-CESS 560	2A	✓	✓	✓	60	560 dia	3500
3430	MIRA X-CESS 600	1B	✓	✓	✓	63	600 dia	3680
3400	MIRA X-CESS 600 Concrete	1A	✓	✓	✓	60	600 dia	3800
3450	MIRA X-CESS 600 Vent	2B	✓	✓	✓	63	600 dia	3680

02 — MIRA X-CESS Range

Stormwater & Gully Grates

Square, rectangular, channel, dish and gully grates for kerbside and carriageway drainage.

Square & Rectangular Stormwater Grate

C250

Product No.	Description	Concave	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
2700	MIRA X-CESS 200×200	✓	✓	6.5	200×200	300×300	40
2750	MIRA X-CESS 300×300	✓	✓	14	300×300	400×400	50
3655	MIRA X-CESS 300×450	✓	✓	20.5	302×450	405×555	50
2765	MIRA X-CESS 340×180	✓	✓	10	340×180	240×240	50
2760	MIRA X-CESS 380×380	✓	✓	21	390×390	500×500	55
2780	MIRA X-CESS 400×600	✓	✓	38	539×330	641×508	60
2770	MIRA X-CESS 450×450	✓	✓	26	450×450	550×550	60
2785	MIRA X-CESS 450×600	✓	✓	40	450×600	520×730	75
2775	MIRA X-CESS 500×500	✓	✓	34	500×500	600×600	55
2890	MIRA X-CESS 520×790	✓	✓	58	510×780	640×910	70
2880	MIRA X-CESS 600×600	✓	✓	42	600×600	700×700	60
2765	MIRA X-CESS 700×700	✓	✓	70	700×700	800×800	80
2885	MIRA X-CESS 800×800	✓	✓	82	800×800	900×900	90

Rectangular Stormwater Grate

D400

Product No.	Description	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
3650	MIRA X-CESS 300×450	✓	33	340×450	470×570	100
3600	MIRA X-CESS 450×600	✓	43	413×610	516×713	75

Square Dish Grate & Frame

B125

Product No.	Description	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
1490	MIRA X-CESS 150×150	✓	2.7	150×150	200×200	34
1500	MIRA X-CESS 230×230	✓	5.3	230×230	290×290	40
1510	MIRA X-CESS 300×300	✓	9.4	300×300	335×335	40
1520	MIRA X-CESS 380×380	✓	16	380×380	480×480	45
1530	MIRA X-CESS 450×450	✓	19	450×450	550×550	45
1540	MIRA X-CESS 600×600	✓	33	600×600	700×700	50

Channel Grates

C250D400

Product No.	Description	Class	Flat	Mass (kg)	Internal (mm)	Height (mm)
2895	MIRA X-CESS Channel Grate	C250	Flat	12	750×200	50
3850	MIRA X-CESS Channel Grate	D400	Flat	22	750×300	50

Gully Grates

B125

Product No.	Description	Mass (kg)	Internal (mm)	Height (mm)
1951	MIRA X-CESS 140 Gulley Grate	0.5	140	18
1950	MIRA X-CESS 190 Gulley Grate	1.2	190	18
1955	MIRA X-CESS Twyford B/Brackets	1.8	Pair	—

03 — MIRA X-CESS Range

Meter, Valve & Hydrant Boxes, Rodding Eye

Stopcock boxes, valve boxes, hydrant boxes and ABC cleaning eyes for civil and plumbing infrastructure.

Stopcock Boxes

B125C250

Product No.	Description	Type	Shape	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
1650	MIRA X-CESS 150×150×100 B125	11A	Rectangle	✓	4.5	150×150	160×195	100
1660	MIRA X-CESS 300×300×100 B125	11D	Rectangle	✓	10.5	300×300	350×350	100

Valve Box

C250

Product No.	Description	Type	Hinged	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
2940	MIRA X-CESS 100×230×300	3A	✓	14	121×235	137×315	310
2920	MIRA X-CESS 100×230×230	3B	✓	11	121×205	155×290	310

Hydrant Box

C250

Product No.	Description	Type	Mass (kg)	Internal (mm)	External (mm)	Height (mm)
2950	MIRA X-CESS 405×275	Sliding lid with rope	26	405×280	550×425	135

ABC Cleaning Eye

B125

Product No.	Description	Shape	Hinged	Mass (kg)
1900	MIRA X-CESS 100×45	Bent	Bolts	3.2
1920	MIRA X-CESS 100×90	Straight	Bolts	2.7
1910	MIRA X-CESS 150×45	Bent	Bolts	5.6
1925	MIRA X-CESS 150×90	Straight	Bolts	5.7

04 — MIRA Rapid Flow Range

Full Bore Roof & Floor Outlet

Threaded dome and flat grates, two-way outlets and PVC adapters for roof and floor drainage.

Threaded Dome Grate

Product No.	Description	Type	Mass (kg)	DN
4500	MIRA Rapid Flow 80×180	Straight	6.9	80
4505	MIRA Rapid Flow 100×180	Straight	9.9	100
4510	MIRA Rapid Flow 150×180	Straight	13.8	150
4515	MIRA Rapid Flow 80×90	90 degree	7.2	80
4520	MIRA Rapid Flow 100×90	90 degree	11.5	100
4525	MIRA Rapid Flow 150×90	90 degree	16.5	150

Threaded Flat Grate

Product No.	Description	Type	Mass (kg)	DN
4550	MIRA Rapid Flow 80×180	Straight	6.9	80
4555	MIRA Rapid Flow 100×180	Straight	9.9	100
4560	MIRA Rapid Flow 150×180	Straight	13.8	150
4565	MIRA Rapid Flow 80×90	90 degree	7.2	80
4570	MIRA Rapid Flow 100×90	90 degree	11.5	100
4575	MIRA Rapid Flow 150×90	90 degree	16.5	150

Two Way

Product No.	Description	Type	Mass (kg)	DN
4530	MIRA Rapid Flow 2 Way 80mm	2 way	8.5	80
4535	MIRA Rapid Flow 2 Way 100mm	2 way	9.2	100

PVC Adapter with Thread

Product No.	Description	Type	Mass (kg)	DN
4580	MIRA Rapid Flow Adapter	PVC	0.19	80
4585	MIRA Rapid Flow Adapter	PVC	0.25	100
4590	MIRA Rapid Flow Adapter	PVC	0.45	150

SSN Coupling & Accessories

EPDM gasket stainless-steel couplings, step irons, and locks & keys.

EPDM Gasket (Stainless Steel) — SSN Coupling

Product No.	Description	Size	Mass (kg)
4040	MIRA S/S Coupling	50×40	0.1
4050	MIRA S/S Coupling	50mm	0.1
4075	MIRA S/S Coupling	75mm	0.1
4100	MIRA S/S Coupling	10mm	0.2
4150	MIRA S/S Coupling	150mm	0.5
4200	MIRA S/S Coupling	200mm	0.6
4250	MIRA S/S Coupling	250mm	0.8
4300	MIRA S/S Coupling	300mm	1.6

Step Irons

Product No.	Description	Type	Mass (kg)	External (mm)
1820	MIRA L/L Step Iron (Brick)	Long leg	1.6	256×160
1800	MIRA S/L Step Iron (Concrete)	Short leg	1.0	185×160

Locks & Keys

Product No.	Description	Type
1994	MIRA Lock	New lock
1998	MIRA Lifting Key	—
1990	MIRA X-CESS Key	—
1997	MIRA X-CESS Key	New lock

Pipe & Pipe Fittings

Ductile iron pipe and fittings — available DN 50–1600, dimensions and testing to ISO 2531/EN 545.

DCI Pipe

Corrosion resistant and readily machinable — an important requirement in any pipe that must be drilled, tapped or cut. Offers the greatest possible margin of safety against service failures due to ground movement and beam stresses.

DN 80–1600 · ISO 2531/EN 545

DCI Push-On Fittings

TYTON® push-on fittings — simple, sturdy, reliable. The Tyton gasket provides a permanent watertight seal through radial compression from the pipe spigot within the finished joint.

DN 80–1600 · Gasket EN 681.1

DCI Fittings for PVC Pipe

A large range of ductile iron fittings available to suit PVC pressure pipes, matched to the same coating and lining options as the rest of the pipe range.

DN 50–400 · BS EN 12842

Coating specification — all pipe & fittings

External coating

Zinc coating + bitumen painting · Liquid epoxy painting · Epoxy applied by FBE · Customised to customer's requirements

Internal coating

Cement mortar lining · Liquid epoxy painting · Epoxy applied by FBE · Customised to customer's requirements
